ENDLESS FLAT SLINGS
SpanSet Endless Flat Slings are manufactured using high-tech webbing, offering enhanced durability and performance. Their continuous loop design allows for versatile use in various lifting configurations, while the robust construction ensures long-lasting reliability under demanding conditions.
- Description
Description
Features
- Wide load (up to 300mm) bearing surface to minimize damage to fragile loads
- Lightweight for enhanced manual handling safety
- Excellent strength to weight ratio
- Light and flexible for good access in awkward situations
- Conform to AS1353.
MADE TO ORDER
Specifications
| RATED WLL (kg) | WIDTH (mm) | THICKNESS (mm) | MIN SLING LENGTH (mm) | MIN PIN DIAMETER (mm) | MIN LOAD EDGE DIAMETER (mm) |
|---|---|---|---|---|---|
| 250 | 25 | 2 | 300 | 2 | 6 |
| 500 | 35 | 2 | 300 | 2 | 6 |
| 1000 | 50 | 3 | 300 | 3 | 9 |
| 2000 | 75 | 4 | 400 | 4 | 12 |
| 3000 | 100 | 4 | 400 | 4 | 12 |
| 4000 | 140 | 4 | 500 | 4 | 12 |
| 5000 | 150 | 4 | 600 | 4 | 12 |
| 6000 | 180 | 4 | 600 | 4 | 12 |
| 8000 | 240 | 5 | 600 | 5 | 15 |
| 10000 | 300 | 5 | 700 | 5 | 15 |
