ULTRA-LINK SYNTHETIC CHAIN
Ultra-Link Synthetic Chain represents the next evolution in chain technology, crafted from multiple layers of high-performance Dyneema® fibre. This cutting-edge material makes the chain up to 85% lighter than steel chain of equivalent strength, allowing for easy manual handling—even in longer lengths—by a single person. Ideal for efficient lifting and lashing applications, Ultra-Link improves safety with its soft touch and reduced weight, minimising injury risk and equipment damage. Dyneema®, the world’s strongest man-made fibre, delivers exceptional strength and durability, making Ultra-Link a premium solution for demanding environments.
- Description
Description
Features
- 8 Times Stronger than steel equivalent
- 85% Lighter than steel equivalent
- With Dyneema – the worlds strongest fiber
- Abrasion and wear resistant material
- Electrically non-conductive
- Patented multi-layered redundant system ensures safety
- Floats on water
- Non-corrosive
- Temperature range is -40 to 70C
- <2.5% Load elongation
- 35-50% More efficient and productive than steel equivalent
- Customized dimensions for any required application and task
- 50,000 cycles abrasion, satisfactorily improved.
Specifications
| MINIMUM BREAKING LOAD (tonne) | WORKING LOAD LIMIT WLL LIFTING (tonne) | LASHING CAPACITY (kg) | WEIGHT (Kg/m) |
|---|---|---|---|
| 10.00 | 2.50 | 5.00 | 0.32 |
| 15.00 | 3.75 | 7.50 | 0.47 |
| 17.00 | 4.38 | 8.75 | 0.58 |
| 20.00 | 5.00 | 10.0 | 0.62 |
| 24.00 | 6.00 | 12.0 | 0.71 |
| 28.00 | 7.00 | 14.00 | 0.83 |
| 32.00 | 8.00 | 16.00 | 0.94 |
| 42.00 | 10.50 | 21.00 | 1.13 |
| 50.00 | 12.50 | 25.00 | 1.18 |
| 52.00 | 13.00 | 26.00 | 1.31 |
| 64.00 | 16.00 | 32.00 | 1.14 |
| 72.00 | 18.00 | 36.00 | 1.75 |
