COMMERCIAL GALVANISED BOW SHACKLE
Commercial Galvanised Bow Shackles are commonly used across domestic, mining, and general industrial applications. Designed for non-critical lifting and connection tasks, these shackles provide a practical solution where rated lifting gear is not essential.
- Description
Description
Features
- Shaped in a either a Bow or Dee pattern, they come with Screw Pin made from mild steel material in hot dipped galvanized.
- NOT FOR LIFTING APPLICATIONS.
Specifications
| SIZE (mm) | WEIGHT (kg) | B (mm) | D (mm) | D1 (mm) | C (mm) | 2R (mm) |
|---|---|---|---|---|---|---|
| 5 | 0.0143 | 10 | 5 | 5 | 19.5 | 15 |
| 6 | 0.026 | 12 | 6 | 6 | 24 | 18 |
| 8 | 0.054 | 16 | 8 | 8 | 32 | 24 |
| 10 | 0.118 | 20 | 10 | 10 | 40 | 30 |
| 12 | 0.225 | 25 | 12 | 12 | 49 | 36 |
| 16 | 0.51 | 32 | 16 | 16 | 64 | 48 |
| 20 | 0.86 | 38 | 19 | 20 | 80 | 60 |
| 22 | 1.35 | 44 | 22 | 22 | 85 | 66 |
| 25 | 2.05 | 50 | 25 | 24 | 100 | 75 |
