This heavy-duty clamp features pressure-resistant polymer for safe horizontal handling of steel and concrete pipes—designed to prevent surface damage during lifting.
- Description
Description
Features
- Jaw openings available up to 70 mm
- Working load limit (WLL) 1,500 – 8,000kg per pair (Higher WLL available upon request)
- Jaw is covered with a special high quality pressure resistant plastic
- Special handle for easy handling
- Compact design and high lifting capacity
- Lightweight design for easy handling
- Tough quality heavy duty body
Specifications
| MODEL | WLL (per pair) (tonnes) | JAW OPENING (mm) | V (mm) | S (mm) | W (mm) | U (mm) | T (mm) | X (mm) | Y (mm) | WEIGHT per piece (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
| 1.5 TPH | 1500 | 40 | 120 | 70 | 50 | 185 | 16 | 41 | 25 | 2 |
| 3 TPH | 3000 | 40 | 120 | 70 | 50 | 185 | 16 | 41 | 25 | 2 |
| 4 TPH | 4000 | 50 | 140 | 70 | 58 | 204 | 26 | 41 | 25 | 3 |
| 6 TPH | 6000 | 50 | 140 | 70 | 58 | 204 | 26 | 41 | 25 | 3 |
| 8 TPH | 8000 | 70 | 140 | 70 | 58 | 224 | 26 | 45 | 25 | 3.4 |
