Triangle equalising plates (also known as monkey or delta plates) are primarily used to balance loads when working with multiple slings and are also suitable for towing applications. Manufactured from high-tensile steel, they are available in a range of sizes to suit various lifting requirements.
- Description
Description
Features
When using multiple sling legs this device provides a means of equalising forces within the legs. Connection is made via standard Grade “S” bow shackle and can be used with chain, wire rope or synthetic slings. Ideal in compensating for differences in load lift points and sling lengths.
Specifications
| DESCRIPTION | MAX. CAPACITY (t) | WEIGHT (kg) | LIFTING LUGS TOP - Grade S Safety Shackle (t) | LIFTING LUGS LOWER - Grade S Safety Shackle (t) | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 5t Equalising Plate | 5 | 10 | 6.5 | 3.5 | 28 | 100 | 35 | 300 | 22 |
| 10t Equalising Plate | 10 | 15 | 12 | 6.5 | 38 | 105 | 45 | 300 | 28 |
| 20t Equalising Plate | 20 | 25 | 25 | 12 | 54 | 130 | 60 | 350 | 38 |
| 30t Equalising Plate | 30 | 40 | 35 | 17 | 60 | 150 | 70 | 450 | 44 |
| 50t Equalising Plate | 50 | 90 | 55 | 35 | 73 | 200 | 105 | 500 | 60 |
| 85t Equalising Plate | 85 | 130 | 85 | 55 | 90 | 225 | 130 | 500 | 73 |
| 120t Equalising Plate | 120 | 190 | 120 | 85 | 100 | 310 | 150 | 600 | 90 |
