6×19 Fibre Core Galvanised Wire Rope is flexible and reliable for marine, winching, slings, pulling, engineering, and general-purpose work where a softer and compliant rope is better suited.
- Description
Description
Features
- 6×19 Fibre Core Galvanized Wire Ropes have a flexible characteristic
- Suitable for, engineering, winch, pulling, marine, slings and general purpose uses wherever rope is required for the application
- Conforms to AS 3569, Test Certificate available with each reel batch
Specifications
| SIZE (mm) | GRADE | FINISH | CORE | LAY | MBF (kN) | APPROX MAX (kg/100m) |
|---|---|---|---|---|---|---|
| 3 | 1570 | Galvanised | Fibre | RHOL | 4.3 | 3.2 |
| 3.5 | 1570 | Galvanised | Fibre | RHOL | 5.8 | 4.3 |
| 4 | 1570 | Galvanised | Fibre | RHOL | 7.7 | 5.8 |
| 5 | 1570 | Galvansed | Fibre | RHOL | 12 | 8.8 |
| 6 | 1570 | Galvanised | Fibre | RHOL | 17.6 | 12.4 |
| 8 | 1570 | Galvanised | Fibre | RHOL | 30.8 | 22.5 |
| 9 | 1570 | Galvanised | Fibre | RHOL | 39 | 28.4 |
| 10 | 1570 | Galvanised | Fibre | RHOL | 48.2 | 35.1 |
| 12 | 1570 | Galvanised | Fibre | RHOL | 69.4 | 50.5 |
